DYMAX GRIZZLY TRASH GRAPPLE RAKE
Dymax Grizzly Trash Grapple Rakes are available for backhoe loaders, WL-30 class wheel loaders and telehandlers working in land clearing and waste handling applications. Operators can quickly stack, load and sort various materials in many applications. Available with machine matched coupler hooks to fit many popular brands.
APPLICATIONS
C&D debris removal; recycling and scrap yard; trees and brush piles; forestry and land clearing; waste handling; transfer station applications. Will handle trash bales.
KEY FEATURES
- 1.00 inch thick tine construction
- Solid reinforced grapples for dozing applications
- 36 inch long smooth tines for easy material
unloading - Solid back plate
- 61″ grapple opening height
Models & Specifications
| TELEHANDLER MACHINES
DX-RK-GRTG-66×8-TH-08K Rake-Grizzly Trash Grapple-66 inch raking width x 8 steel tines-Telehandler-8000 lb class Standard Features: 1.00 inch A572 Tines 8 total, Solid HD grapples for dozing applications, Smooth tines for easier unloading, 36.6 inch tine length,61” grapple open height Weight 2,180 lbs |
| WHEEL LOADER
DX-RK-GRTG-66×8-WL-30 Rake-Grizzly Trash Grapple-66 inch raking width x 8 steel tines-Wheel Loader-Class 30 Standard Features: 1.00 inch A572 Tines 8 total, Solid HD grapples for dozing applications, Smooth tines for easier unloading, 36.6 inch tine length,61” grapple open height Weight 2,180 lbs |
Design and specifications are subject to change without notice. Contact Dymax for custom built solutions 1-800-530-5407.
GALLERY
