DYMAX LOADER RAKE WITH GRAPPLES

Dymax Loader Rakes with Grapples are tough and dependable attachments used for debris removal in many applications. Operators can easily grip piles of brush, logs, mulch, compost and trash. All models feature high strength steel tines.

Download Brochure Get a Quote

DX-RK-LRDG – Loader Rake with Dual Grapple

7549D1_GR7549-LOADER RAKE WITH DUAL GRAPPLE

KEY FEATURES

High strength T1 steel rake tines for durability
10 inch tine spacing on average
Stow legs for ease of uncoupling
Cushion valve package for grapple
Coupler hooks to fit many popular coupler sizes
Custom models available upon request

APPLICATIONS

Loading tub grinders or stacking debris
Construction site cleanup
Land clearing
Brush and tree handling
Material sorting
Log handling
Mulch and composting

DX-RK-LRFG – Loader Rake with Full Width Grapple

SPECIFICATIONS

Loader Rake - Dual Grapple - Models

Machine Operating Weight 20,000-24,000 lbs

Model No. DX-RK-LRDG-102×10-WL-40

Rake-Loader with Double Grapple-102 inch raking width x 10 steel tines-Wheel Loader-Class 40

• 10 inch tine spacing – 10 total tines • 1.25 inch A514 T1 steel tines • Two independent grapples • Clamp opening of 81.3 inches • 3.5×12.0 cylinder • Stow legs

Weight 4,200 lbs

Machine Operating Weight 26,000-31,000 lbs

Model No. DX-RK-LRDG-102X8-WL-50

Rake-Loader with Double Grapple-102 inch raking width x 8 steel tines-Wheel Loader-Class 50

• 12 inch tine spacing – 8 total tines • 1.50 inch A514 T1 steel tines • Two independent grapples • Clamp opening of 81.3 inches x 18.5 min diameter close • 4.0×12.0 cylinder • Stow legs

Weight 4,400 lbs

Machine Operating Weight 26,000-31,000 lbs

Model No. DX-RK-LRDG-105×10-WL-50

Rake-Loader with Double Grapple-105 inch raking width x 10 steel tines-Wheel Loader-Class 50

• 10 inch tine spacing – 10 total tines • 1.50 inch A514 T1 steel tines

• Two independent grapples • Clamp opening of 81.3 inches

• 4.0×12.0 cylinder • Stow legs

Weight 4,800 lbs

Machine Operating Weight 32,000-38,000 lbs

Model No. DX-RK-LRDG-117×11-WL-60

Rake-Loader with Double Grapple-117 inch raking width x 11 steel tines-Wheel Loader-Class 60

• 10 inch tine spacing – 11 total tines • 1.50 inch A514 T1 steel tines • Two independent grapples • Clamp opening of 84 inches • 4.0×12.0 cylinder • Stow legs

Weight 5,400 lbs

Machine Operating Weight 40,000-47,500 lbs

Model No. DX-RK-LRDG-130×12-WL-70

Rake-Loader with Double Grapple-130 inch raking width x 12 steel tines-Wheel Loader-Class 70

• 10 inch tine spacing – 12 Total tines • 1.75 inch A514 T1 steel tines • Two independent grapples • Clamp opening of 84 inches • 4.0×12.0 cylinder • Stow legs

Weight 5,850 lbs

Machine Operating Weight 48,000-56,000 lbs

Model No. DX-RK-LRDG-143×13-WL-80

Rake-Loader with Double Grapple-143 inch raking width x 13 steel tines-Wheel Loader-Class 80

• 10 inch tine spacing, – 13 total tines • 1.75 inch A514 T1 steel tines • Two independent grapples • Clamp opening of 84 inches • 4.0×12.0 cylinder • Stow legs

Weight 6,500 lbs

Design and specifications are subject to change without notice. Contact Dymax sales for more information or custom solutions 1-800-530-5407.

Loader Rake - Full Width Grapple - Models

Machine Operating Weight 20,000-24,000 lbs

Model No. DX-RK-LRFG-102×10-WL-40

Rake-Loader Rake with Full Width Grapple-102 inch raking width x 10 steel tines-Wheel Loader-Class 40

• 10 inch tine spacing – 10 total tines • 1.25 inch A514 T1 steel tines

• Full width grapple • Clamp opening of 81.3 inches

• 3.5×12.0 cylinder • Stow legs

Weight 4,300 lbs

Machine Operating Weight 26,000-31,000 lbs

DX-RK-LRFG-105×10-WL-50

Rake-Loader Rake with Full Width Grapple-105 inch raking width x 10 steel tines-Wheel Loader-Class 50

• 10 inch tine spacing – 10 total tines • 1.50 inch A514 T1 steel tines • Full width grapple • Clamp opening of 81.3 inches • 4.0×12.0 cylinder • Stow legs

Weight 4,900 lbs

Machine Operating Weight 40,000-47,500 lbs

Model No. DX-RK-LRFG-130×12-WL-70

Rake-Loader Rake with Full Width Grapple-130 inch raking width x 12 steel tines-Wheel Loader-Class 70

STANDARD FEATURES:

• 10 inch tine spacing – 12 Total tines • 1.75 inch A514 T1 steel tines • Full width grapple • Clamp opening of 84 inches • 4.0×12.0 cylinder • Stow legs

Weight 6,000 lbs

Machine Operating Weight 48,000-56,000 lbs

Model No. DX-RK-LRFG-143×13-WL-80

Rake-Loader Rake with Full Width Grapple-143 inch raking width x 13 steel tines-Wheel Loader-Class 80

• 10 inch tine spacing, – 13 total tines • 1.75 inch A514 T1 steel tines • Full width grapple • Clamp opening of 84 inches • 4.0×12.0 cylinder • Stow legs

Weight 6,600 lbs

Design and specifications are subject to change without notice. Contact Dymax sales for more information or custom solutions 1-800-530-5407.
