DYMAX LOADER CLEARING RAKES

FOR WHEEL LOADERS AND BACKHOE LOADERS

Dymax Loader Rakes are ideal for land clearing applications. Operators can easily remove unwanted vegetation, trees and brush. These loader rakes are built tough using high-strength steel tines and are excellent for stacking and collecting materials.

APPLICATIONS

Utility right of way maintenance; land remediation; vegetation management; roadside clearing; debris sorting and stacking; burn pile and site cleanup

KEY FEATURES

High-strength T1 steel rake tines with 12 inch spacing
Tree Pusher Bar
Serrated back-drag bar
Coupler hooks to fit many popular coupler sizes
Custom models available upon request

SPECIFICATIONS

Models & Specifications

15,000-19,000 lbs machine operating weight class

Model DX-RK-LR-89×10-WL-30

Rake-Loader Rake-89 inch raking with x 11 steel tines-Wheel Loader-Class 30

1.0 inch thick T1 steel tines – 11 total tines • 12 inch tine spacing on average • Serrated back drag bar with tree pusher top rack • Stowing legs for ease of removal from loader

1150 lbs

16,500-24,000 lbs machine operating weight class

Model DX-RK-LR-96×10-BL-10

Rake-Loader Rake-96 inch raking width x 10 tines-Backhoe Loader-Class 10

1.0 inch thick T1 steel tines – 10 total tines • 12 inch tine spacing on average • Serrated back drag bar with tree pusher top rack • Stowing legs for ease of removal from loader

1250 lbs

25,000-30,000 lbs machine operating weight class

Model DX-RK-LR-96×10-BL-20

Rake-Loader Rake-96 inch raking width x 10 tines-Backhoe Loader-Class 20

1.0 inch thick T1 steel tines – 10 total tines • 12 inch tine spacing on average • Serrated back drag bar with tree pusher top rack • Stowing legs for ease of removal from loader

1250 lbs

20,000 to 24,000 lb machine operating weight class

Model DX-RK-LR-102×10-WL-40

Rake-Loader Rake-102 inch raking width x 10 steel tines-Wheel Loader-Class 40

1.25 inch thick T1 steel tines – 10 total tines • 12 inch tine spacing on average • Serrated back drag bar with tree pusher top rack • Stowing legs for ease of removal from loader

2950 lbs

26,000-31,500 lbs machine operating weight class

Model DX-RK-LR-105×10-WL-50

Rake-Loader Rake-105 inch raking width x 10 steel tines-Wheel Loader-Class 50

1.50 inch thick T1 steel tines – 10 total tines • 12 inch tine spacing on average • Serrated back drag bar with tree pusher top rack • Stowing legs for ease of removal from loader

3000 lbs

32,000-38,000 lbs machine operating weight class

Model DX-RK-LR-117×11-WL-60

Rake-Loader Rake-117 inch raking width x 11 steel tines-Wheel Loader-Class 60

1.50 inch thick T1 steel tines – 11 total tines • 12 inch tine spacing on average • Serrated back drag bar with tree pusher top rack • Stowing legs for ease of removal from loader

3350 lbs

40,000-47,500 lbs machine operating weight class

Model DX-RK-LR-130×12-WL-70

Rake-Loader Rake-130 inch raking width x 12 steel tines-Wheel Loader-Class 70

1.75 inch thick T1 steel tines – 12 total tines • 12 inch tine spacing on average • Serrated back drag bar with tree pusher top rack • Stowing legs for ease of removal from loader

4250 lbs

48,000-56,000 lbs machine operating weight class

Model DX-RK-LR-143×13-WL-80

Rake-Loader Rake-143 inch raking width x 13 steel tines-Wheel Loader-Class 80

1.75 inch thick T1 steel tines – 13 total tines • 12 inch tine spacing on average • Serrated back drag bar with tree pusher top rack • Stowing legs for ease of removal from loader

4650 lbs

Design specifications are subject to change without notice. For special design requirements, unique tine spacing or options please contact Dymax sales 1-800-530-5407
