SKELETON ROCK GRAPPLE BUCKET
For Wheel Loaders
SPECIFICATIONS
| Model Code Description Width Weight |
|||
| DX-BK-SRGL-2.50cyd-WL-40
Bucket-Skeleton Rock Grapple-2.50 cyd capacity-Wheel Loader-Class 40 STANDARD FEATURES: high strength T1 steel tines, replaceable Caterpillar style bolt-on adapters and tips, 4 inch tine spacing, side profile to accommodate handling pipe materials, dual grapples with grapple control valve kit. WIDTH: 100 inches WEIGHT: 4200 lbs |
|||
| DX-BK-SRGL-4.50cyd-WL-60
Bucket-Skeleton Rock Grapple-4.50 cyd capacity-Wheel Loader-Class 60 STANDARD FEATURES: high strength T1 steel tines, replaceable Caterpillar style bolt-on adapters and tips, 4 inch tine spacing, side profile to accommodate handling pipe materials,, dual grapples with grapple control valve kit. WEIGHT: 5800 lbs |
|||
| DX-BK-SRGL-3.00cyd-WL-50
Bucket-Skeleton Rock Grapple-3.00 cyd capacity-Wheel Loader-Class 50 STANDARD FEATURES: high strength T1 steel tines, replaceable Caterpillar style bolt-on adapters and tips, 4 inch tine spacing, side profile to accommodate handling pipe materials, dual grapples with grapple control valve kit, 100 inches wide WEIGHT: 4400 lbs |
Design and specifications are subject to change without notice. Please contact Dymax sales for custom solutions 1-800-530-5407.
HYDRAULIC REQUIREMENTS
| Your machine will require 3rd function auxiliary lines.
CIRCUIT 1 – Clamp Operation Type – Two way Flow/Pressure – GPM (min/max) 15-25, PSI (max) 3,000 |
|||
| NOT SUPPLIED: Does not include jumper hoses to machine lines or quick disconnects. |
