BALE GRAPPLE BUCKET

For Wheel Loaders

The Dymax Bale Grapple Bucket is a heavy-duty attachment that is specially designed for handling bales of trash at balefill locations, refuse transfer stations and landfills. Operators can efficiently stack, carry and unload up to two bales at a time, making it ideal for loading trucks or placing bales directly into the landfill.

In addition to its specialized bale-handling capabilities, the Bale Grapple Bucket functions as a conventional grapple for handling loose trash and various materials.

It’s the go-to solution for waste management professionals who need a strong, dependable, multi-functional tool.

Key Features

  • Independent grapple design with bolt-on bale hooks for handling and stacking trash bales efficiently.
  • Replaceable bolt-on cutting edge and rear wear pads for extended durability.
  • Open side plate design with heavy-duty 1.50 inch T1 corners for reinforced strength.
  • Bottom high-tensile steel wear plates and center push screen for improved performance in waste handling applications.
  • Hydraulic cushion valve package with relief for smooth and controlled operation.
  • Available in 2.00 yd³, 2.50 yd³, and 3.00 yd³ capacities, with widths ranging from 94 to 105 inches.

Model Code
Description
Width
Weight
DX-BK-GLBF-2.00cyd-WL-30

Bucket-Grapple Balefill Transfer Station-2.00 cyd capacity-Wheel Loader-Class 30

Waste Handling Applications: handles 2 bales of trash from end loaded and stacks bales + loose trash.

STANDARD FEATURES: OEM replaceable bolt-on cutting edge, cushion valve package with relief, independent grapple design with bolt-on bale hooks, bottom high tensile steel wear plates and rear wear pads, open side plate design with heavy duty 1.50in T1 corners, center push screen and trash guard.

WIDTH: 94 inches

WEIGHT: 2560 lbs
DX-BK-GLBF-2.50cyd-WL-40

Bucket-Grapple Balefill Transfer Station-2.50 cyd capacity-Wheel Loader-Class 40

Waste Handling Applications: handles 2 bales of trash from end loaded and stacks bales + loose trash.

STANDARD FEATURES: OEM replaceable bolt-on cutting edge, cushion valve package with relief, independent grapple design with bolt-on bale hooks, bottom high tensile steel wear plates and rear wear pads, open side plate design with heavy duty 1.50in T1 corners, center push screen and trash guard.

WIDTH RANGE: 98-102 inches

WEIGHT: 3150 lbs
DX-BK-GLBF-3.00cyd-WL-50

Bucket-Grapple Balefill Transfer Station-3.00 cyd capacity-Wheel Loader-Class 50

Waste Handling Applications: handles 2 bales of trash from end loaded and stacks bales + loose trash.

STANDARD FEATURES: OEM replaceable bolt-on cutting edge, cushion valve package with relief, independent grapple design with bolt-on bale hooks, bottom high tensile steel wear plates and rear wear pads, open side plate design with heavy duty 1.50in T1 corners, center push screen and trash guard.

WIDTH RANGE: 102-105 inches

WEIGHT: 3450 lbs
Design and specifications are subject to change without notice.  Please contact Dymax sales for custom solutions 1-800-530-5407.
Your machine will require 3rd function auxiliary lines.

CIRCUIT 1 – Clamp Operation

Type – Two way

Flow/Pressure – GPM (min/max) 15-25, PSI (max) 3,000
NOT SUPPLIED: Does not include jumper hoses to machine lines or quick disconnects.
